73-87 CHEVY F/S 1940 WHITE Truck/Blazer/Suburban
73-87 CHEVY F/S 1940 WHITE Truck/Blazer/Suburban
Will work with 88-91 Squarebody Trucks, Blazers and Suburban's
New Vintage USA complete gauge packages for 1973-1987 GM full size trucks are designed to install in the factory location and update the style and functions in the dash. Each kit is hand assembled in Detroit and features NVUÂ?s unique mounting bracket, CNC laser cut and formed to precise specifications for a superior fit.
Kits include NVU exclusive mounting bracket and hardware, 4-3/8" programmable speedometer, 4-3/8" programmable tachometer operates on any cylinder configuration, 2-1/16" oil pressure, water temperature, volt and 0-90 fuel gauge. (0-90 ohm factory match fuel gauge utilizes stock sender-not included). Sender bushings, jumper wiring harnesses where required and programming button.
Bold styling
Dome Lenses
Easy programming and setup
Built-in indicators (Turn signal, hi beam, warning lights)
4-3/8" Speedometer 140 MPH programmable with 1 auxiliary input
4-3/8" Tachometer 8,000 RPM with TWO auxiliary inputs
2-1/16" Fuel gauge(0-90 ohm setting)
Temperature gauge 140-280 F
Oil pressure gauge 0-100 PSI
Voltmeter 9-17V
2 ea AMP connector harnesses
2 ea Programming buttons
Bushing kit
Oil pressure sender 99100-04 (1/8-27 NPT, 240-33 Ω)
Temperature sender 99230-04 (1/8-27 NPT, NVU hi match)
73-87 GM Truck bracket
